The AON-M2 is a high temperature, industrial 3D printer that can fabricate the highest performance thermoplastics. Print bigger and better with its actively heated build chamber and large build volume.
Affordable hardware and materials plus the largest build volume in its class make AON3D’s additive manufacturing platform accessible to businesses of all sizes.
3D Print PEEK, PEKK, ULTEM™, Carbon fiber and glass fiber composites, and affordable prototyping materials.
Affordable hardware and materials plus the largest build volume in its class make AON3D’s additive manufacturing platform accessible to businesses of all sizes.
AON3D is more than just a hardware provider - you get to tap into their team of materials engineers, polymer focused PhD's, and application consultants to help you successfully complete your projects.
High Performance Materials
Designed to print aerospace-grade thermoplastics, including PEEK, PEKK, Ultem™, carbon fiber filled variants, and many more.
135ºC Chamber Temperature
High build chamber and bed temperatures are crucial for ensuring first layer adhesion, preventing warping and improving interlayer bonding.
Build Bigger & Make More
The 18" x 18" x 25" build envelope allows you to print bigger, or run batch jobs of multiple parts at once.
Liquid-Cooled Precision
The stepper motors and both hot ends are cooled with a liquid cooling loop, which extends component lifetimes and offers accurate control over the melt-zone while extruding.
Double the Design Opportunities
Dual independent toolheads allow you to design parts using multiple materials, such as soluble supports, or quickly switch between two different nozzle sizes.
Dedicated Expert Support
Expert materials and engineering support come with every machine, including on-site training with each 3D printer delivery.
Easy Remote Management
Remotely manage your print queue and machine from any device on the same network. No software installation required.
Printing Technology
Fused Filament Fabrication, or Fused Deposition Modeling (FFF, FDM)
Build Volume
450 x 450 x 565 mm
18 x 18 x 22.8 in
Build Platform Material
Vacuum Bed for Swappable Build Surfaces
PC & PEI sheets
Carbon Fiber PEEK sheet
Material-Specific Build Sheets
Build Platform Leveling
Adaptive mesh leveling
Dual, fully independent
Layer Resolution
0.005” (125 micron, all Axis, real-world application)
50-500 Micron Standard Layers
Speeds
Travel Speed: 500mm/s
Printing speeds depend on material
Filament Diameter
Standard 1.75mm Filament
Open Material System
Nozzle Diameter
Hardened Steel: 0.2,0.3,0.4,0.6,0.8, 1.0, 1.2 mm
Position Accuracy
XY: 25 μm Z: 1 μm
Regulatory Compliance
CE, CSA/UL available upon request
Warranty
AON3D Warranty
Extruder Temperature
500°C+
Build Plate Temperature
200°C
Chamber Temperature
135°C
Forced Convective Air Flow
A thermal optimized, precision-controlled build chamber ensures static printing temperatures.
Input File Type
Power Consumption
208-240 VAC, 50/60Hz,
single phase L6-20 outlet, European adapter available
110/120v outlet for vacuum pump
Machine Dimensions
Machine Dimensions:
945 x 806 x 1440 mm
Recommended Footprint:
2000 x 2000 x 3000 mm
Installation Size:
1150x955x1450mm
Shipping Weight & Dimensions
43 x 46 x 63 inches
870lbs
Materials
Any 1.75mm Filament, including: ABS, ASA, Nylon (PA66, PA6, PA12), PC,PEEK, PEKK, PETG, PSU, PPSU, TPC, TPU, ULTEM™Carbon fiber and glass-filled variants of the above + Various soluble and break-away support materials, Open Material System
Affordable industrial 3D printing is finally here. The AON-M2 unlocks the innovative power of additive manufacturing, at a fraction of the cost.
Avoid getting tied down with costly proprietary polymers, and experience the freedom of choosing between leading chemical companies.
Choose from materials that can replace metals, with properties that can withstand the harshest operating conditions.
STARTING AT
MSRP plus around $10-20k
of required accessories
Call or email sales@visionminer.com
for a detailed quote
