EinScan Libre

The Shining 3D EinScan Libre is a versatile, all-in-one 3D scanner designed for seamless, high-resolution scanning with true-to-life color. Its flexible modes, wireless capabilities, and efficient performance make it an excellent choice for professionals across various industries, offering both precision and convenience.

Key Features:

  • Ease of Use: Simple and intuitive interface
  • Wireless Operation: No cables required
  • Powerful Processor: Built-in NVIDIA processor
  • Integrated Display: View scans directly on the device
  • Dual Light Sources: Laser and IR for versatile scanning
  • Three Versatile Modes: Adapt to various objects and environments
  • High-Resolution Scanning: Captures fine details accurately
  • True-to-Life Color Capture: 48 MP color camera for vivid results
  • Flexible, Multitasking Workflow: Adaptable to different resolutions
  • Outdoor Compatibility: Efficient under direct sunlight
  • User-Friendly Software: Simplified operation and control

$26,099.00

Financing Options Available!

Email contact@visionminer.com and ask for a 60-second application :)

BEST FOR LARGE SCANS

The EinScan Libre combines advanced laser and infrared technologies, making it perfect for capturing challenging surfaces like dark and reflective materials. Whether you're scanning large objects like furniture or intricate details on small parts down to the size of a pen cap, the EinScan Libre delivers high-resolution results with a point distance as fine as 0.05mm. Its versatile scanning modes, including full-color capture, provide excellent accuracy and detail for a wide range of applications.


  • Multiple Scan Options

    Handheld Rapid IR for portable, rapid full-color scanning

    Handheld Laser Scan for capturing objects with black or reflective surfaces

  • Powerful Software

    Includes EXSCAN Libre scanning software, which features a new and improved user interface and workflow

  • High Accuracy & Resolution

    IR and Laser projection ensure high accuracy.

    The accuracy in laser scan mode is up to 0.04 + 0.06 mm/m

  • Scan Small to Large

    With full color infrared and laser modes, possibilities are practically endless.

  • High Speed

    20 FPS 1,200,000 points/s (rapid scan) or
    120 FPS 1,600,000 points/s (laser scan)

  • Endless Applications

    Use the EinScan Libre for high-quality reverse engineering, manufacturing, 3D modeling, customized products, scanning industrial parts, sculptures, artifacts, human bodies, healthcare, research, education, virtual displays, and more.

NEW!

Metrology Bundle

Reverse Engineering & Design

Metrology Bundle Includes:

- EinScan Libre

- Pelican Style Travel Case

- ExModel Pro License

$30,399.00

MORE EINSCAN LIBRE VIDEOS COMING SOON!

For now, take a look at our world first premiere video!

EXAMPLE SCAN FILES

Download these files to check out the resolutions possible on the Scanner!

Import them into your Mesh software, or CAD software, like Fusion 360 or Solidworks, and take a look!

Some files contain just an STL, others contain the full ASC data and other files.

Mercedes E320 First Scan Test

Horse Sculpture Art

Painting Sculpture

Large Industrial Tubes

Shiny Artwork

EinScan LibreEinScan LibreEinScan LibreEinScan LibreEinScan LibreEinScan Libre

Detailed Specifications (EinScan Libre)

Scan Mode

IR Rapid: IR VCSEL

IR Adaptive

Laser HD: 101 Blue Laser Lines

Volumetric Accuracy*

Up to 0.04 + 0.06 mm/m

Up to 0.04 + 0.06 mm/m

Up to 0.04 + 0.06 mm/m

Safety

Class II (eye-safe)

Class II (eye-safe)

Class II (eye-safe)

Light Source

White Light, visible

White Light, visible

Blue Laser

Scan & Align Speed

2.7 million points/second

1.9 million points/second

4.5 million points/second

Align Modes

Markers / Global Markers / Feature / Texture / Hybrid

Markers / Global Markers

Markers / Global Markers / Feature / Texture / Hybrid

Resolution (Point Distance)

0.5 - 10 mm

0.5 - 10 mm

0.05 - 3.0 mm

Maximum FOV

370 × 470 - 983 × 979 mm

370 × 470 - 779 × 835 mm

165 × 200 - 382 × 450 mm

Working Distance

500 - 1500 mm

500 - 1200 mm

200 - 500 mm

Certification

CE,FCC,ROHS,WEEE,KC


Dimensions

162 × 182 × 266 mm

Color Camera Resolution

48 MP

3D Camera Resolution

5 MP

Output Formats

OBJ; STL; ASC; PLY; P3 ; 3MF;LAS

Scanner Body Weight

1.8 kg (with battery), 1.6 kg (without battery)

Operating Temperature Range

0-40℃

Operating Humidity Range

10-90%

Warranty

1 Year Manufacter Warranty

Software

Device installed scanning software

PC software EXScan Libre

* Volumetric accuracy refers to the relationship between 3D data accuracy and object size; the accuracy is reduced by 0.1mm per 100cm(standard scan & body scan). The conclusion is obtained by measuring the center of sphere under marker alignment.

$26,099.00

WARRANTY INFORMATION

Looking for Geomagic Essentials?



Shining3D now offers new bundles with ExModel, as Geomagic Essentials has been replaced. ExModel makes reverse engineering easier, faster, and simpler with its improved tools and features. If you still need any Geomagic programs or have questions about the transition, just give us a call or shoot us an email and we'll be happy to help you out.
