Einscan HX2

The EinScan HX2 provides hybrid blue laser and LED light scanning for a wider range of object size compatibility.

Key Features:

• Handheld Hybrid LED / Infrared 3D Scanner

• Designed for Body, Limb, and Face Scanning

• Easy to Scan Large Objects and Organic Shapes

• Full color texture capturing included

• 0.1mm Maximum Resolution / Point Distance

EinScan HX

$7,999.00

REQUEST A QUOTE

EinScan HX2 ExModel Bundle

$13,999.00

REQUEST A QUOTE

Financing Options Available!

Email contact@visionminer.com and ask for a 60-second application :)

GOOD FOR DARK, REFLECTIVE, AND LARGE SCANS

The blue lasers of the EinScan HX2 make capturing dark parts, reflective parts like metal a breeze. The HX2 is also best for large scans, like car bumpers, and scans in full color during structured light mode.



The HX2 offers VERY high resolution scans, at 0.05mm point distance.

Still works fantastic for tiny parts! Excellent detail, for parts down to the size of a pen cap, or smaller.

VIDEOS: Operation Tips & Tricks

Quick Links:

Product Brochure

Warranty Options

Software Download

Scan File Download

Multiple Scan Options

Handheld Rapid Scan for portable, rapid full-color scanning

Handheld Laser Scan for capturing objects with high accuracy (50 microns)

Powerful Software Included

Includes EXSCAN HX2 scanning software, which features a new and improved user interface and workflow

High Accuracy & Resolution

Triangulation and structured light projection ensure high accuracy.

The accuracy in laser scan mode is always 0.04mm, with scan resolution from 3mm to 0.05mm

Scan Small to Large

With full color structured light scans and laser modes, possibilities are practically endless.

High Speed

20 FPS 1,200,000 points/s (rapid scan) or
120 FPS 1,600,000 points/s (laser scan)

Many Applications

Use the EinScan HX2 for high-quality reverse engineering, manufacturing, 3D modeling, customized products, scanning industrial parts, sculptures, artifacts, human bodies, healthcare, research, education, virtual displays, and more.

EXAMPLE SCAN FILES

Download these files to check out the resolutions possible on the Scanner!

Import them into your Mesh software, or CAD software, like Fusion 360 or Solidworks, and take a look!

Some files contain just an STL, others contain the full ASC data and other files.

SEE MORE SCAN FILES (Google Drive)

AIR COMPRESSOR

Download Files

CAR FENDER

Download Files

GLOCK 17

Download Files

WHEEL HUB

Download Files

CAR DOOR

Download Files

ENGINE VALVE COVER

Download Files

Benchy

Download Files

BUILT FOR
REVERSE ENGINEERING

Scan objects, vehicles, parts, textures, tools, devices, etc
EinScan HX Shining3D 3D Scanner
EinScan HX Shining3D 3D Scanner
EinScan HX Shining3D 3D Scanner
EinScan HX Shining3D 3D Scanner
EinScan HX Shining3D 3D Scanner
EinScan HX Shining3D 3D Scanner

Detailed Specifications (EinScan HX2)

Scan Mode

Rapid Scan

Laser Scan

Scan Accuracy

Up to 0.05 mm

Up to 0.04 mm

Volumetric Accuracy*

0.05+0.1 mm/m

0.04+0.06 mm/m

Safety

LED light (eye-safe)

Class 1 (eye safe)

Light Source

Blue LED

Blue Laser

Scan & Align Speed

1,200,000 points/s, 20FPS+

1,060,000 points/s, 20FPS+

Align Modes

Markers Alignment, Feature Alignment, Hybrid Alignment, Texture Alignment

Markers Alignment

Depth of Field

200 - 700 mm

350 - 610 mm

Maximum FOV

420 mm * 440 mm

380 mm * 400 mm

Point Distance

0.25 mm - 3 mm

0.05 mm - 3 mm

Working Distance

470mm

Built-in Color Camera

Yes

Dimensions

108 mm * 110 mm * 237mm

Output Formats

OBJ; STL; ASC; PLY; P3 ; 3MF

Scanner Body Weight

710g

Operating Temperature Range

0-40ºC

Operating Humidity Range

10-90%

Supported OS

Windows 10/11

Recommended PC Configuration

Win10,11(64bit)

Recommended Configuration

- Intel Core i7-12700 or higher processor (Works with AMD, Intel recommended)

- 32GB of RAM or more

- NVIDIA GTX/RTX series cards, higher or equal to GTX 3060

- 6 GB minimum VRAM and 32 GB minimum RAM

- USB 3.0 connection



Please Note: Not compatible with AMD Graphics Cards. nVidia required.

Minimum PC Configuration

- Intel Core i7-8700 or higher processor (Works with AMD, Intel recommended)

- 16GB of RAM or more

- NVIDIA GTX/RTX series cards, higher or equal to GTX 2060

- 4 GB minimum VRAM and 32 GB minimum RAM

- USB 3.0 connection



Please Note: Not compatible with AMD Graphics Cards. nVidia required.

Connection Standard

USB 3.0

Warranty

1 Year Manufacter Warranty

Certification

CE，FCC，ROHS，WEEE，KC

* Volumetric accuracy refers to the relationship between 3D data accuracy and object size; the accuracy is reduced by 0.1mm per 100cm(standard scan & body scan). The conclusion is obtained by measuring the center of sphere under marker alignment.
