EinScan HX Reverse Engineering Design Bundle – Vision Miner

EinScan HX

The EinScan HX provides hybrid blue laser and LED light scanning for a wider range of object size compatibility.

Key Features:

  • Handheld Hybrid Blue Laser / LED 3D Scanner
  • Designed for Reflective and Black objects
  • Easy to Scan Large Objects
  • Full color texture capturing included
  • 0.04mm (0.0015") Maximum Resolution

$12,000.00

Financing Options Available!

Email sales@visionminer.com and ask for a 60-second application :)

BEST FOR LARGER, DARK, REFLECTIVE OBJECTS

  • Multiple Scan Options

    Handheld Rapid Scan for portable, rapid full-color scanning

    Handheld Laser Scan for capturing objects with high accuracy (50 microns)

  • Powerful Software

    Includes EXSCAN HX scanning software, which features a new and improved user interface and workflow, and Solid Edge SHINING 3D Edition CAD software, a design tool from SIEMENS PLM Software that allows reverse engineering and design from scan data with the ability to export to Solidworks or other CAD programs.

  • High Accuracy & Resolution

    Triangulation and structured light projection ensure high accuracy.

    The accuracy in laser scan mode is 0.04mm, and resolution is down to 0.05mm

  • Scan Small to Large

    With full color and laser modes, possibilities are practically endless.

  • High Speed

    20 FPS 1,200,000 points/s (rapid scan) or 55 FPS 480,000 points/s (laser scan)

  • Endless Applications

    Use the EinScan HX for high-quality reverse engineering, manufacturing, 3D modeling, customized products, scanning industrial parts, sculptures, artifacts, human bodies, healthcare, research, education, virtual displays, and more.

RED BUNDLE

Reverse Engineering & Design

RED Bundle Includes:

- EinScan HX Scanner

- Pelican Travel Case

- Solid Edge Shining3D Edition

- Geomagic Essentials ($1000 Savings!)

$12,000.00

VIDEOS

EXAMPLE SCAN FILES

Download these files to check out the resolutions possible on the Scanner!

Import them into your Mesh software, or CAD software, like Fusion 360 or Solidworks, and take a look!

Some files contain just an STL, others contain the full ASC data and other files.

AIR COMPRESSOR

(717mb)

CAR DOOR

(279mb)

CAR FENDER

(120mb)

ENGINE VALVE COVER

(119mb)

WHEEL HUB

(120mb)

MORE EXAMPLES COMING SOON!

BUILT FOR

REVERSE ENGINEERING

AND PART VALIDATION

Detailed Specifications (EinScan HX)

Scan Mode

Rapid Scan

Laser Scan

Scan Accuracy

Up to 0.05 mm

Up to 0.04 mm

Volumetric Accuracy*

0.05+0.1 mm/m

0.04+0.06 mm/m

Safety

LED light (eye-safe)

LED light (eye-safe)

Light Source

White Light, visible

White Light, visible

Scan & Align Speed

1,200,000 points/s, 20FPS

480,000 points/s, 55FPS

Align Modes

Markers Alignment, Feature Alignment, Hybrid Alignment, Texture Alignment

 Feature Alignment

Depth of Field

200 - 700 mm

350 - 610 mm

Maximum FOV

420 mm * 440 mm

380 mm * 400 mm

Point Distance

0.25 mm - 3 mm

0.5 mm - 3 mm

Camera Frame Rate

55 FPS

Working Distance

470 mm

Built-in Color Camera

Yes

Texture Scan

Yes

No

Dimensions

108 mm * 110 mm * 237mm

Color Scanning

Support

Output Formats

OBJ; STL; ASC; PLY; P3 ; 3MF

Scanner Body Weight

710g

Operating Temperature Range

0-40℃

Operating Humidity Range

10-90%

Supported OS

Windows 10 (64bit)

Recommended Configuration

- Intel Core i7-8700 or higher processor

- NVIDIA GTX/RTX series cards, higher or equal to GTX 1080

- 4 GB minimum VRAM and 32 GB minimum RAM

- USB 3.0 connection


Please Note: Not compatible with AMD processors.

Connection Standard

USB 3.0

Warranty

1 Year Manufacter Warranty

Certification

CE,FCC,ROHS,WEEE,KC


* Volumetric accuracy refers to the relationship between 3D data accuracy and object size; the accuracy is reduced by 0.1mm per 100cm(standard scan & body scan). The conclusion is obtained by measuring the center of sphere under marker alignment.

Einscan HX

(includes scanner and travel case)
$9,999.00

HX RED Bundle

(includes scanner, travel case,
and GeoMagic Essentials software)
$12,000.00

Caveat Emptor:

Training Packages are available, if needed.

RETURNS ARE NOT ACCEPTED FOR 3D SCANNERS.

Manufacturer Warranty always applies.
