THERMAX™ PPS [POLYPHENYLENE SULFIDE] 3D Filament

Product attributes include:

• Melting temperature (Tm) of 285°C
• Glass Transition Temperature (Tg) of 85°C
• Excellent chemical resistance - insoluble in ANY known solvent under 200°C
• Inherent flame resistance
• Long-term hydrolytic stability - very low moisture absorption
• Exceptional strength and modulus, even at elevated temperatures
• Stable dielectric constant and dissipation factor over a wide range of temperatures and frequencies

Filament Specifications:

• Diameter: 1.75mm (+/- 0.05mm)
• Color: Dark Grey

Recommended Print Conditions:

• Extruder Temp: 315 - 345°C (all-metal extruder)
• Bed Temp: 120 - 160°C
• Chamber Temp: 60 - 90°C (if available on your printer)
• Bed Prep: Nano Polymer Adhesive
• Drying Instructions: Please see the following instructions for when you want to dry out this filament, HERE.

Annealing (post crystalizing) 3D Printed PPS Parts: Parts printed with PPS must be annealed after printing to ramp-up the crystallinity in the resin. This will maximize mechanical, thermal, and chemical resistance properties. Full annealing generally requires 2-4 hours of heating at 130°C. The following process for annealing your ThermaX™ PPS parts will help assure ideal performance.

• Step 1: Place printed parts in cool, room-temp oven. Supports may be left on the part if there is a risk of warping.
• Step 2. Set temp to 80°C and allow to stabilize for 1 hour.
• Step 3: Raise oven temperature to 130°C, and allow to stabilize 2-3 hours, longer depending upon the size/thickness of the part.
• Step 4: Turn off oven heat and allow the printed part to cool to room temperature.

ThermaX™ is a trademark of 3DXTECH, it's owners, and affiliates.
